Electric - Passanger Jumbo L5 Catagory

An urban mobility vehicle #goGreen #goEV.

Variant	Passanger 4 + D
Vechicle Category	L3
Seating Capacity	4+D
Vechicle Root Type	CaNopy
Dimension-(LxWxH)	2780x990x1750
Wheel Base-mm	2140
Ground Clearance	130
Turning Radious-m	1050
Vechicle Kerb Weight	320
top speed-Km/hr	24.5
Certified Range-Km	24.5
Typical Driving Range-Km	22
	Lead Acid/
Battery Type ,Voltage	Lithium
Battery Capacity (Kwh)	48V120AH
Charging Time	5-6 HRS
Swap Enabled	yes
Peak Power-Kw	1.80KW
Transmission Type	-
Suspension-Front	Hydraulic / Helical
Suspension-Rear	Leaf Spring
Brakes-Front/Rear	Mechanical
Wind Screen and Wiping System	Yes
Spare Wheel Provision	No
Driving Modes	Manual
Economy and Boost mode	Economy
Lockable Glove box	Yes
Grab Handles	Yes
12V Socket for phone charging	Yes
GPS	No
Hazard Indicators	Yes
Roof mounted grab handle bar	Yes

Variant	Passanger 3+ D
Vechicle Category	L5
Seating Capacity	3+D
Vechicle Root Type	CaNopy Closed For Driver
Dimension-(LxWxH)	2970x1470x1855
Wheel Base-mm	1950
Ground Clearance	135
Turning Radious-m	1250
Vechicle Kerb Weight	390
top speed-Km/hr	45
Certified Range-Km	45
Typical Driving Range-Km	35

Battery Type ,Voltage	Lithium
Battery Capacity (Kwh)	60V140AH
Charging Time	4-5 HRS
Swap Enabled	Yes
Peak Power-Kw	5.10 KW
Transmission Type	Direct Transmission through + Trans axial
Suspension-Front	Hydraulic /
Suspension-Rear	Helical Spring + Dampener Telescopic
Brakes-Front/Rear	Mechanical
Wind Screen and Wiping System	Yes
Spare Wheel Provision	No
Driving Modes	Manual
Economy and Boost mode	Economy
Lockable Glove box	Yes
Grab Handles	Yes
12V Socket for phone charging	Yes
GPS	No
Hazard Indicators	Yes
Roof mounted grab handle bar	Yes
